SMART SERIES
- 80 PLUS Bronze certified efficiency
- DC-to-DC technology
- OCP and OTP Protection
- Long Life 9cm fan
TECHNICAL SPECIFICATIONS
Model |
Smart 450 W |
Article no. |
BFX-450BS |
EAN code |
0753263077493 |
Weight (wthout/with package) |
1.03 kg / 1.5 kg |
AC input |
100 - 240 V / 7.0A |
Frequency |
47 - 63 Hz |
+5V |
20.0 A |
+3.3 V |
20.0 A |
+5 V & +3.3 V combined |
120 W |
+12 V1 |
37.5 A |
+12V2 |
- |
+12V1, +12V2 combined |
450 W |
P.F. |
>0.9 |
-12 V |
0.3 A / 3.6 W |
+ 5VBS |
2.5 A / 12.5 W |
Maximum Power |
450 W |
Connectors |
20+4 PIN ATX |
1 |
8 PIN EPS (4+4) |
1 |
8 PIN PCIe (6+2) |
2 |
SATA |
3 |
MOLEX |
2/1 |
Cable length (mm) |
20+4 PIN ATX |
350 |
8 PIN EPS (4+4) |
350 |
8 PIN PCIe (6+2) |
350 / 150 |
SATA |
3 x 250 |
MOLEX / FLOPPY |
2 x 150 / 150 |
Features |
ATX12V Version |
ATX 12V 2.3 |
Efficiency |
80+ Bronze |
Dimension (D x W x H) |
100 x 125 x 64mm |
PFC |
Active PFC (0,9) |
Fan |
90 mm silent fan |
Security |
AFC (Automatic Fan speed Control) OCP (Overcurrent protection) OPP (Overload protection) OTP (Over-temperature protection) OVP (Overvoltage protection) SCP (Short-circuit protection) SIP (Surge & Inrush Protection) UVP (Under Voltage protection) |
Warranty |
24 Months |
