Specifikace
Model Code |
LS24C360EAUXEN |
|---|
| Display |
|---|
Screen Size (Class) |
24 |
|---|
Flat / Curved |
Curved |
|---|
Active Display Size (HxV) (mm) |
521.3952 x 293.2848mm |
|---|
Screen Curvature |
1800R |
|---|
Aspect Ratio |
16:9 |
|---|
Panel Type |
VA |
|---|
Brightness (Typical) |
250 cd/m2 |
|---|
Brightness (Min) |
200 cd/m2 |
|---|
Contrast Ratio (Static) |
3,000:1(Typ.) |
|---|
Contrast Ratio (Dynamic) |
N/A |
|---|
HDR(High Dynamic Range) |
N/A |
|---|
HDR10+ |
N/A |
|---|
Mini LED Local Dimming |
N/A |
|---|
Resolution |
1,920 x 1,080 |
|---|
Response Time (ms) |
4(GTG) |
|---|
Viewing Angle (H/V) |
178°(H)/178°(V) |
|---|
Color Support |
Max 16.7M |
|---|
Color Gamut (NTSC) |
72% |
|---|
Color Gamut (DCI Coverage) |
N/A |
|---|
Color Gamut (sRGB Coverage) |
N/A |
|---|
Color Gamut (Adobe RGB Coverage) |
N/A |
|---|
Frame Rate |
Max 75Hz |
|---|
| General Feature |
|---|
Eco Saving Plus |
Yes |
|---|
0.00 W Off mode |
N/A |
|---|
Eye Saver Mode |
Yes |
|---|
Flicker Free |
Yes |
|---|
Picture-In-Picture |
N/A |
|---|
Picture-By-Picture |
N/A |
|---|
Quantum Dot Color |
N/A |
|---|
Game Mode |
Yes |
|---|
Image Size |
Yes |
|---|
Daisy Chain |
N/A |
|---|
Windows Certification |
Windows 10 |
|---|
FreeSync |
Yes |
|---|
G-Sync |
N/A |
|---|
Adaptive-Sync |
N/A |
|---|
Off Timer Plus |
N/A |
|---|
Black Equalizer |
N/A |
|---|
Low Input Lag Mode |
N/A |
|---|
Virtual AIM Point |
N/A |
|---|
Core Sync |
N/A |
|---|
Game Bar |
N/A |
|---|
Gaming Hub |
N/A |
|---|
Refresh Rate Optimizor |
N/A |
|---|
Super Arena Gaming UX |
N/A |
|---|
HDMI-CEC |
N/A |
|---|
Auto Source Switch |
N/A |
|---|
Adaptive Picture |
N/A |
|---|
Super Ultrawide GameView |
N/A |
|---|
| Smart Service |
|---|
Smart Type |
N/A |
|---|
Operating System |
N/A |
|---|
Bixby |
N/A |
|---|
Far-Field Voice Interaction |
N/A |
|---|
Built-in Voice Assistant |
N/A |
|---|
Works with Google Assistant |
N/A |
|---|
TV Plus |
N/A |
|---|
Universal Guide |
N/A |
|---|
Video Communication |
N/A |
|---|
Web Service |
N/A |
|---|
SmartThings |
N/A |
|---|
Tap View |
N/A |
|---|
Workspace |
N/A |
|---|
| Interface |
|---|
Wireless Display |
N/A |
|---|
D-Sub |
1 EA |
|---|
DVI |
N/A |
|---|
Dual Link DVI |
N/A |
|---|
Display Port |
N/A |
|---|
Display Port Version |
N/A |
|---|
Display Port Out |
N/A |
|---|
Display Port Out Version |
No |
|---|
Mini-Display Port |
N/A |
|---|
HDMI |
1 EA |
|---|
HDMI Version |
01.IV |
|---|
HDCP Version (HDMI) |
01.IV |
|---|
Micro HDMI |
N/A |
|---|
Micro HDMI Version |
N/A |
|---|
HDCP Version (Micro HDMI) |
N/A |
|---|
Audio In |
N/A |
|---|
Headphone |
Yes |
|---|
USB Ports |
N/A |
|---|
USB Hub Version |
No |
|---|
USB-C |
N/A |
|---|
USB-C Charging Power |
N/A |
|---|
Thunderbolt Input |
N/A |
|---|
Thunderbolt Charging Power (Port 1) |
N/A |
|---|
Thunderbolt Charging Power (Port 2) |
N/A |
|---|
Version of Thunderbolt |
N/A |
|---|
Ethernet (LAN) |
N/A |
|---|
WiFi |
N/A |
|---|
Bluetooth |
N/A |
|---|
Built-in Camera |
N/A |
|---|
Windows Hello Certification |
N/A |
|---|
| Audio |
|---|
Speaker |
N/A |
|---|
Adaptive Sound |
N/A |
|---|
| Operation Conditions |
|---|
Temperature |
10~40 °C |
|---|
Humidity |
10~80, Non-condensing % |
|---|
| Calibration |
|---|
Factory Tunning |
N/A |
|---|
Built in Calibration Engine |
N/A |
|---|
LUT(Look-up Table) Bit Depth |
N/A |
|---|
Gray Balance |
N/A |
|---|
Uniformity Correction |
N/A |
|---|
Color Mode |
N/A |
|---|
CMS(Color Management Software) |
N/A |
|---|
Factory Calibration Report |
N/A |
|---|
| Design |
|---|
Front Color |
BLACK |
|---|
Rear Color |
BLACK |
|---|
Stand Color |
Black high Glossy+Etching |
|---|
Stand Type |
ROUND SIMPLE |
|---|
HAS(Height Adjustable Stand) |
N/A |
|---|
Tilt |
-2.0o(±2.0o) ~ 22o(±2.0o) |
|---|
Swivel |
N/A |
|---|
Pivot |
N/A |
|---|
Wall Mount |
75.0 x 75.0 |
|---|
| Eco |
|---|
Energy Efficiency Class |
E |
|---|
Recycled Plastic |
N/A |
|---|
| Power |
|---|
Power Supply |
AC 100~240V |
|---|
Power Consumption (Max) |
25W W |
|---|
Power Consumption (Typ) |
17.0 W |
|---|
Power Consumption (DPMS) |
0.30 W |
|---|
Power Consumption (Off Mode) |
0.30 W |
|---|
Power Consumption (Yearly) |
22 kWh/year |
|---|
Type |
External Adaptor |
|---|
| Dimension |
|---|
Set Dimension with Stand (WxHxD) |
547.8 x 416.3 x 214.0 mm |
|---|
Set Dimension without Stand (WxHxD) |
547.8 x 325.6 x 108.2 mm |
|---|
Package Dimension (WxHxD) |
612.0 x 162.0 x 390.0 mm |
|---|
| Weight |
|---|
Set Weight with Stand |
3.1 kg |
|---|
Set Weight without Stand |
2.6 kg |
|---|
Package Weight |
4.8 kg |
|---|
| Accessory |
|---|
Power Cable Length |
1.5 m |
|---|
D-Sub Cable |
N/A |
|---|
DVI Cable |
N/A |
|---|
HDMI Cable |
Yes |
|---|
HDMI to DVI Cable |
N/A |
|---|
HDMI to Micro HDMI Cable |
N/A |
|---|
DP Cable |
N/A |
|---|
Mini-Display Port Cable |
N/A |
|---|
USB Type-C Cable |
N/A |
|---|
Thunderbolt 3 Cable |
N/A |
|---|
Thunderbolt 4 Cable |
N/A |
|---|
Install CD |
N/A |
|---|
USB 2.0 Cable |
N/A |
|---|
USB 3.0 Cable |
N/A |
|---|
Remote Controller |
N/A |
|---|
Camera |
N/A |
|---|
| Disclaimer |
|---|
Disclaimer |
N/A |
|---|
| Certification and Compliance |
|---|
UL Glare Free |
N/A |
|---|
Pantone Validated |
No |
|---|
TCO Certified |
N/A |
|---|
