TECHNICAL SPECIFICATIONS
 Socket type
Intel LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1356 & LGA1366
 Cooler dimension
90 x 89 x 42.5 mm
 Heatsink material
Pure copper
 Weight
605g
 Installation
Screws and backplate
 Fan dimension
70 x 70 x 15 mm
 Fan speed
3000 - 6000 RPM...

prečítať celé



TECHNICAL SPECIFICATIONS
|  Socket type |
Intel LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1356 & LGA1366 |
|  Cooler dimension  |
90 x 89 x 42.5 mm |
|  Heatsink material |
Pure copper |
|  Weight |
605g |
|  Installation |
Screws and backplate |
|  Fan dimension |
70 x 70 x 15 mm |
|  Fan speed |
3000 - 6000 RPM |
|  Fan airflow |
46.98 CFM (76.24 m3/h) |
|  Fan air pressure |
8.94 mm H2O |
|  Noise level |
29.1 - 46.5 dB(A) |
|  Current rating |
0.40A |
|  Voltage rating |
12V DC |
|  Bearing type |
Twin Ball Bearing |
|  Fan life expectancy |
50,000 hours |
|  Fan connector |
3pin |
|  Product code |
AK-CC7302BT01 |
